Equipment

The EMF has a range of equipment and wet lab areas specifically for sample preparation and imaging of biological samples.

We offer a full sample preparation and imaging service or user training and supervision.

Transmission Electron MicroscopeJEOL JEM-1400 TEM

  • Transmission Electron Microscope
  • 120kV Tungsten Filament
  • EMSIS Xarosa 10MP digital camera

Applications

  • Resin embedded cells and tissues
  • Negative staining proteins and macromolecules
  • Nanoparticle analysis
  • Tomography
  • Immunogold labelling
  • CLEM

Hitachi S3000H SEM Scanning electron MicroscopeHitachi S3000H SEM

  • Scanning electron Microscope
  • 30kV tungsten filament
  • Secondary electron detector

Applications

  • Bacteria and Biofilms
  • Micro-organisms
  • Surface morphology of animal and plant tissue
  • Surface morphology of cell cultures

UltramicrotomesUltramicrotomes

  • Leica UC7
  • Reichert Ultracut E
  • RMC MT-7

Quorum Q150 TES coating unitQuorum Q150 TES coating unit

  • Turbo molecular pump
  • Vacuum to 5 x 10-5 mbar
  • Easy multi choice menu options
  • Au/pd, Chromium or Platinum targets
  • Argon or air gas supply

Applications

  • Glow discharging
  • Plasma cleaning
  • Sputter coating
  • Carbon coating
  • Aperture cleaning

Polaron SC7640 Sputter coaterPolaron SC7640 Sputter coater

  • Manual or automatic control
  • Gold target
  • Argon gas supply

Bal-tec CPD 030 Critical Point DryerBal-tec CPD 030 Critical Point Dryer

  • Large high pressure chamber
  • Liquid CO2 exchange medium
  • Acetone, Amyl acetate or ethanol transition fluids

Applications

  • Drying large or delicate samples for SEM imaging
  • Model organisms
  • Tissue biopsies
  • Plant and insect
  • Cells and micro-organisms
